Features:

• Ideal for small & medium sized companies
• Drills drawer side components in a variety of sizes
• Loading magazine for automatic operation
• 2 horizontal heads with 5 spindles, 32 mm distance
• High adjustments in heads for different
  thicknesses
• 3 vertical heads with multi-drilling spindles, according to customer specification
• Loading magazine for 20" high stack
• Opens and closes easily with digital readout, positioned in the linear bearing tracks
• Easy to operate - requires only one operator
• Drills approximately 20-22 pieces per minute
• Drilling capacity: Width; Minimum 2", Maximum 42" Length; Minimum 16" Maximum 42".

Specifications:

• PLC controls
• Linear bearings on precision slides
• Hold-down clamps
• Dust extraction hoods
• Power: 220, 440, 600V, 3 phase
• Size: 48" wide x 75" long x 50" high
• Weight: approximately 1500 lbs
• Colour: white
