Features:

• Designed to accommodate small and
  large workshops
• Operated by turning a handle without the
  use of tools
• Cylinders are automatically positioned
  with length or width are set for the
  clamping size
• Parts can be clamped in two directions at
  the same time, or independently
• Four cylinders, two vertical and two
  horizontal are provided per section and
  clamp against a square fence

Benefits:

• Saves time
• Increases production because of
  its simple operation
• Low initial cost and easy set up
• All components are constructed from top
  quality materials and are well designed
  and built for reliable performance
• Easy access for cleaning

Specifications:

• Minimum clamping 10” x 10”
• Maximum clamping 24” x 42”
  (other sizes available upon request)
• Steel tubing frame
• Heavy duty steel slides and fence
• Filter regulator and lubricator
• Four cylinders per section, 2-1/2” bore,
  2” stroke
• 491 pounds force per cylinder at
  100 PSI air
