• Quick change hopper magazine with a loading capacity of 35 hinges
• Insertion slide with UHMW non-wearing plastic
• Creates chip-free bores on melamine and other sensitive materials by drilling from below
• Boring head with hard gear and spindles
• Linear bearings on slides for up and down movement
• Dust extraction hood with 4" diameter
• No tools required for precision depth adjustments
• Double safety controls with metal detector and photo eye, prevents boring unit from cycling again into the previously installed hinge

Specifications:

• PLC controls
• 90 PSI air required
• Power: 220, 440, 600V, 3 phase
• Minimum width of working piece, 3", maximum 12"
• Minimum length of working piece, 8", maximum 56"
